Hardware Design
Schematics, PCB layout, DFM-minded designs, bring-up support.
Focus
Schematics + PCB + Bring-up
Strength
DFM + Clean layout
Delivery
Production-ready outputs
Description
I design reliable schematics and production-ready PCBs with a practical focus on signal integrity, power design, DFM/DFT, and clean documentation. I can support the full cycle from architecture and component selection to bring-up checklists and first-board debugging.
Hardware pipeline
Step 1
Requirements
Step 2
Schematic
Step 3
PCB Layout
Step 4
Bring-up
Top 6 Projects from 25+ builds
Marine CTD Measurement System
Measures conductivity, temperature, and depth of seawater and stores the data on an onboard SD card.
motionSense Device
motionSense is a low-power 9 axis IMU data logger with RS232/RS485 connectivity.
LTE Cellular Chipset
Designed a multi-layer PCB optimized for LTE RF performance and signal integrity.
GNSS Module
High-performance BDS/GNSS multimode receiver with integrated RF front end, baseband processor, and 32-bit RISC CPU.
Plug-and-Play Smart Modems
Plug-and-play PCB with a 20-pin header and integrated SMA connector for seamless customer testing.
Cellular Evaluation Boards
Feature-rich evaluation PCBs integrating audio codec, USB interfaces, SD card, RF and GNSS antennas, audio jack, and GPIO expansion.
